Automatic Poked Roll Type Vertical Labeling Machine NCT-21100

Vertical type Automatic Labeling Machine. It adopt vertical type transmission, vertical type labelling, more stable, more precise and improve working efficiency.

$9,558.20 CAD
*
()

Introduction

Vertical type Automatic Labeling Machine. It adopt vertical type transmission, vertical type labelling, more stable, more precise and improve working efficiency.
It's applied to label the self-adhesive label on various largesize cylinder products, as wine bottle, zip-top can, abluent etc.
"This machine is widely used in electrical, pharmacy, foodstuff, beverage, cosmetic and chemical industries. It can be modified to double label, more advanced, more high working efficiency, save more time and cost.

Specifications

Model NC-T-21100
Labeling speed 30-200pcs/min (depends on products and labels size)
Label size (W)20-150mm/(L)20-320mm
Products size Diameter: φ25mm-φ90mm Height: 25mm-300mm
Label reel Inner diameter 76mm/Outer diameter 280mm
Accuracy ±1mm(depends on product and label size)
Voltage 220V 50HZ/110V 60HZ
Machine size(L x W x H) 1950mm*1100mm*1300mm

Remarks

  • Adopt mature technology PLC control system, operation is stable and high-speed;
  • Using touch-screen control operating system, simple, practical, efficient;
  • Adapt variety shape of object in top labeling;
  • Screw adjustment to suppress body movements accurately;
  • Synchronization chain mechanism ensure labeling smooth and precise calibration;
  • Advanced technology of pneumatic code system, print batch number and expiry clearly.
  • Transmission-type rolling bottles, make sure the labels attached more firmly;
  • Labeling transparent label without bubble and wrinkle;
  • All are made of stainless steel and high quality aluminum alloy.
